Partial Ossicular Replacement

PE Partial

PE Partial

L = Total Length
FL = Functional Length

Item No. Dimensions Qty/Box
PAP 07.10 Total Length (L): 5.00 mm
Columella O.D.: 2.10 mm
1
PE Offset Partial

PE Offset Partial

Item No. Dimensions Qty/Box
TPL 07.02 Total Length (L): 5.00 mm
Columella O.D.: 1.80 mm
1
Dense HA Partial

Dense HA Partial

Columella O.D.: 2.10

Item No. Length (mm) Qty/Box
PAP 07.12.300 3.00 1
PAP 07.12.350 3.50 1
PAP 07.12.400 4.00 1
PAP 07.12.450 4.50 1
PAP 07.12.500 5.00 1
HA Offset Partial

HA Offset Partial

Columella O.D.: 2.00

Item No. Length (mm) Qty/Box
TPL 07.06.300 3.00 1
TPL 07.06.350 3.50 1
TPL 07.06.400 4.00 1
TPL 07.06.450 4.50 1
TPL 07.06.500 5.00 1
TPL 07.06.550 5.50 1
Dense HA 90° Oval Head Partial

Dense HA 90° Oval Head Partial

Columella O.D.: 2.00

Item No. Length (mm) Qty/Box
PAP 07.15.300 3.00 1
PAP 07.15.350 3.50 1
PAP 07.15.400 4.00 1
PAP 07.15.450 4.50 1
PAP 07.15.500 5.00 1
Dense HA 75° Oval Head Partial

Dense HA 75° Oval Head Partial

Columella O.D.: 2.00

Item No. Length (mm) Qty/Box
PAP 07.16.300 3.00 1
PAP 07.16.350 3.50 1
PAP 07.16.400 4.00 1
PAP 07.16.450 4.50 1
PAP 07.16.500 5.00 1
Dense HA Malleable Partial

Dense HA Malleable Partial

  • Platinum wire

Columella O.D.: 2.00

Item No. Length (mm) Qty/Box
TPL 07.08.350 3.50 1
TPL 07.08.400 4.00 1
TPL 07.08.450 4.50 1
TPL 07.08.500 5.00 1
TPL 07.08.550 5.50 1
TPL 07.08.600 6.00 1
Dense HA and PE Partial with Malleable Head

Dense HA and PE Partial with Malleable Head

Item No. Dimensions Qty/Box
PAP 07.41 Total Length (L): 6.50 mm
Head: 3.50 mm
Platinum wire O.D.: 0.25 mm
Columella external O.D: 2.20 mm
1
PE Partial with Malleable Gold Head

PE Partial with Malleable Gold Head

  • Trimmable PE columella
Item No. Dimensions Qty/Box
PAP 07.47 Total Length (L): 6.50 to 2.75 mm
Gold Wire O.D.: 0.30 mm
Columella O.D.: 1.80 mm
Columella I.D.: 1.20 mm
1
GOLD and PE Partial with Malleable Head

GOLD and PE Partial with Malleable Head

  • Extendable stem
Item No. Dimensions Qty/Box
PAP 07.49 Total Length (L): 2.75 to 6.50 mm
Head: 3.00 mm
Gold Wire O.D.: 0.30 mm
Columella O.D.: 1.80 mm
Columella I.D.: 1.20 mm
1
Dense HA Telescopic Universal Partial / Total

Dense HA Telescopic Universal Partial / Total

Item No. Length (mm) Qty/Box
PAP 07.19.350 3.50 min / 4.20 max 1
PAP 07.19.400 4.00 min / 4.70 max 1
PAP 07.19.450 4.50 min / 5.20 max 1
PAP 07.19.500 5.00 min / 5.70 max 1
PAP 07.19.550 5.50 min / 6.20 max 1
PAP 07.19.600 6.00 min / 6.70 max 1
Titanium Partial

Titanium Partial

Columella O.D.: 1.30 / Columella I.D.: 1.10

Item No. Length (mm) Qty/Box
PAP 07.62.175 1.75 1
PAP 07.62.200 2.00 1
PAP 07.62.225 2.25 1
PAP 07.62.250 2.50 1
PAP 07.62.275 2.75 1
PAP 07.62.300 3.00 1
PAP 07.62.325 3.25 1
PAP 07.62.400 4.00 1
PAP 07.62.450 4.50 1
PAP 07.62.500 5.00 1
Titanium Adjustable Partial

Titanium Adjustable Partial

  • Extendable stem
Item No. Dimensions Qty/Box
PAP 07.64 Total Length (L): 2.00 to 6.00 mm
Head size: 3.50 x 2.50 mm
1
Titanium Partial with Slits in Bell

Titanium Partial with Slits in Bell

Columella O.D.: 1.30 / Columella I.D.: 1.10

Item No. Length (mm) Qty/Box
12705 0.50 1
12710 1.00 1
12712 1.25 1
12715 1.50 1
12717 1.75 1
12720 2.00 1
12722 2.25 1
12725 2.50 1
12730 3.00 1
12735 3.50 1
Titanium Partial Offset with Malleus Groove

Titanium Partial Offset with Malleus Groove

Item No. Length (mm) Qty/Box
12805 0.50 1
12810 1.00 1
12812 1.25 1
12815 1.50 1
12817 1.75 1
12820 2.00 1
12822 2.25 1
12825 2.50 1
12830 3.00 1
12835 3.50 1
Titanium Partial

Titanium Partial

Item No. Length (mm) Qty/Box
12905 0.50 1
12910 1.00 1
12912 1.25 1
12915 1.50 1
12917 1.75 1
12920 2.00 1
12922 2.25 1
12925 2.50 1
12930 3.00 1
12935 3.50 1
Titanium Adjustable Partial Trimmable Shaft

Titanium Adjustable Partial Trimmable Shaft

  • Trimmable in 1 mm increments
Item No. Length (mm) Qty/Box
12100 5.50 to 2.50 mm 1
12200 5.00 to 2.00 mm 1
